CS2 Plus

$8.00

Chatillon® CS2Plus Digital Force Testers

The Chatillon® CS2Plus digital force testers are revolutionary systems optimized for production testing applications, including medical devices, plastics, packaging, textiles, rubber and electronics to name a few. No personal computer is required; no proprietary software is required; no knowledge of programming languages is required. This easy, flexible and affordable Tester uses a 2 in 1 Laptop Console in both Production and Laboratory environments.

Two options are available. Both the CS2Plus-225 and CS2Plus-1100 provide an easy-to-use, intuitive and straightforward method for tensile, compression, sheer, flexural, peel, or advanced multi-stage testing that conform to ISO or ASTM testing procedures. With the CSPlus Series you can perform:

  • Limit testing to load, displacement, height or time

  • Break testing – sharp or percentage

  • Multi-stage, cyclic tests and height measurements

  • Peel testing

  • Spring Testing

  • Capture 2nd Peak

  • RS-232 Auto Result Export

When repetitive testing and exporting of results is important, but you don’t need advanced materials test functionality, the CS2Plus is an excellent choice.

  • Force Capacity: CS2+225 225 lbf/1000 N | CS2+1100 1124 lbf/5000 N
  • Speed Accuracy (unloaded): ± 1% of selected speed
  • Crosshead Displacement Accuracy (unloaded): ± 0.25% of reading
  • Displayed Displacement Resolution: 0.001 in /0.01 mm
  • Load Cell Force Accuracy (non-dedicated): ± 0.25% full scale of load cell capacity
  • Load Cell Force Accuracy (dedicated): ± 0.10 % full scale of load cell capacity
  • Useable Data Sampling Rate: 1000 Hz

Limit and Break Testing
Setup a test based on a load, displacement, height, or time limit in both tensile and compression directions. Similarly, a break or rupture can be defined as a sharp break or percentage drop from the peak load measured.

As an added feature, a quick test button (compression or tension) allows the user to define and execute a test with only a few clicks, reducing setup time for trial and error testing.

Multi-Stage & Cycle Testing
The multi-stage setup allows users to configure virtually any type of test setup imaginable. Each part of a test is defined as a “stage”. Each stage can be set up with its own independent load or displacement characteristic and speed. The touch screen interface with stage specific icons provides an excellent overview and makes it easy to add, edit or delete a stage.

Multi-stage testing can be used for cycle, hold, insertion/extraction, snap-on/off, switch toggle, or other sophisticated test methods. Users have total freedom to create the test movement required, using their sample without the need for expensive 3rd-party software applications or validation requirements.

Height Mode
The CS2Plus includes a height mode of operation that allows the user to perform pre-conditioning and then measure height at specific loads. The system has an automatic datum routine that defines the reference point for height measurements. An Absolute Distance Feature allows driving to a specific distance in reference to zero.

Peel Testing
Determine the maximum and average peeling force of various materials between two points that you define in the test program setup.
