FG-3000 Series

$5.00

The new FG-3000 Series digital force gaugesare the choice for simple, cost-effective tension and compression testing. Combining one of themost compact housings, yet maintaining a large back-lit LCD,these units were designed to fit perfectly in the hand for ease ofuse. The multi-language FG-3000’s provide menu programmingfor intuitive set-up of the instrument to your desired requirements.Three modes of operation are selectable: Track mode displayslive readings, Peak mode records the maximum reading sensedduring the test, and Pre-set mode which activates user definedhigh and low limit set points. The programmable limits provide aquick visual and audible indication if a test passes or fails. In addition, a comparator output enables integration of the instrumentinto your quality system for repetitive testing such as on production lines.

  • Accuracy: ± 0.3% F.S.
  • Selectable Units: N, gf, kgf, ozf, and lbf. (Depending on Range)
  • Data Sampling Rate: 1000 Hz
  • Overload Capacity: 150% of F.S. (LCD flashes beyond 110% of F.S.)
  • Measurement Method: Peak, Track, Preset
  • Data Sampling Rate: 1000 Hz
  • Display: 160*128 dot matrix LCD with Backlight

Features

  • 1000 Hz Sample Rate combined with +/-0.3% F.S. accuracy provides fast sampling producing greatresolution and more accurate results.
  • Three mode operation: Track, Peak & Preset Limits.
  • 180° reversible display, tension/compression icons, and vertical printed keypad allows usage as a portable gauge ormounted upside down on a test stand.
  • Programmable High & Low Limits allow for instant visual and audible indication of pass or fail testing in Preset mode.
  • 500 point data collection capability can be viewed on display, sent to optional printer, or uploaded to software packagefor further analysis.
  • Rugged, ergonomic die cast aluminum construction allows usage in demanding applications.
  • Comparator output function provides user with easy Pass/Fail testing system integration capabilities.
  • Multi-language and engineering unit’s selection provides flexible user comfort
  • Field Calibration capability eliminates need to send to lab.
  • Calibration Certificate included along with popular adapter attachments.
  • Free Data logging/graphing software available for free download on website.
