Series 2 digital force gauges are designed for basic tension and compression forcetesting applications up to 500 lbF (2,500 N). Peak tension and compression readingsare reliably captured via the gauges’ ±0.5% accuracy and 500 Hz sampling rate. Abacklit graphic LCD displays the current, peak tension, or peak compression reading.
The gauges are overload protected to 200% of capacity. An ergonomic, reversiblealuminum housing allows for hand held use or fixture mounting, rugged enough forapplications in both production and laboratory environments. Series 2 gauges are directlycompatible with Mark-10 test stands and grips.
Accuracy: ±0.5% of full scale
Sampling Rate: 500 Hz
Power: AC or rechargeable battery, with multi-step low battery indicator.
Battery life: Backlight on: Up to 7 hours of continuous use
Safe overload: 200% of full scale (display shows “OVER” at 110% and above)
Weight: M2-2 – M2-100: 0.7 lb [0.33 kg], M2-200 – M2-500: 0.9 lb [0.41 kg]
